Electronic product-related process soldering flux Clear, transparent and highly active liquid soldering flux
| Place of Origin | China |
|---|---|
| Brand Name | Wuxi Top Chemical |
| Certification | ISO9001 |
| Model Number | THC11 |
| Minimum Order Quantity | 10 tons |
| Price | Call/negotiable |
| Packaging Details | 1 container |
| Delivery Time | 5-8 days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 500 tons/month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | High Solid Flux | Suggested Thinner | FD5050 Thinner |
|---|---|---|---|
| Odor | Organic Solvent | Advantages | No-cleaning |
| Solid Content (w/w) | 12.0±0.5 | Acid Value (mg KOH/g) | 25±5 |
| Specific Gravity (g/ml) | 0.810±0.008 | Storage Time | 12 Months |
Product Description
Electronic product-related process soldering flux Clear, transparent and highly active liquid soldering flux
1. Features and advantages:
Preheating makes the flux on the circuit board dry, enhancing the removal of oxides and the formation of good solder joints.
When foam coating is used, compressed air with degreasing and dewatering is used to foam, so that sufficient flux can be maintained on the foam core.
Use a pressure regulator to adjust the air pressure to produce uniform bubbles and optimal height.
The flux applicator needs to add a thinner to compensate for the loss of evaporation and maintain the balance of the flux composition.
TUOPU THC11 flux is a flux with high solid content (12% solid content) and higher activity. It can be used in foaming, spraying and other forms.
2.Exposure precautions:
Engineering control: Use only in well-ventilated places and closed systems. Emergency showers and eyewashes are provided in the workplace.
Personal protective equipment:
①Respiratory protection: filter type gas mask for industrial use.
② Eye protection: safety goggles.
③Skin protection: rubber gloves.
④Body protection: anti-static work clothes, anti-smashing shoes.
3. Technical indicators
| Parameter | Typical Value |
| Appearance | light yellow, clear and transparent liquid |
| Specific gravity (g/ml) | 0.810±0.008 |
| Odor | organic solvent |
| Flash point (T.C.C) | 14℃ |
| Insulation resistance | >108Ω |
| Solid content (w/w) | 12.0±0.5 |
| Storage time | 12 months |
| p H value | weak acid |
| Acid value (mg KOH/g) | 25±5 |
4.Hazard identification information:
| Eye contact: 500ppm concentration can irritate the eyes or splash into the eyes can also irritate the eyes. |
| Skin contact: Direct contact may cause skin irritation. |
| Inhalation hazard: Inhalation of high concentrations may cause nausea and irritation of the nose and throat; long-term inhalation of high concentrations may cause vomiting or loss of consciousness. |
| Ingestion hazards: cause vomiting, diarrhea, and even life-threatening. |
5.Solder Liquid Flux picture
