High Conductivity 25C Electric Motor Coil Insulating Varnish Pcb Conformal Coating Types
| Place of Origin | China |
|---|---|
| Brand Name | Wuxi Top Chemical |
| Certification | ISO9001 |
| Model Number | 8562E |
| Minimum Order Quantity | 1 tons |
| Price | Call/negotiable |
| Packaging Details | 1 container |
| Delivery Time | 5-8 days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 50 tons/month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Main Ingredients | Modified Alkyd Resin And Amino Resin | Appearance | Full Gloss/varnish |
|---|---|---|---|
| Color | ≤3 Gardner (Gardner Standard) | Proportion | About 0.92 |
| Viscosity | 30±2Sec(25℃ Ford Cup#4) | Solid Content | About 43% |
| The Baking Temperature | Generally Not Less Than 80℃ | Shelf Life | 6 Months |
| High Light | high conductivity electric motor coil insulating varnish,80C electric motor coil insulating varnish,pcb conformal coating types Moisture proof |
||
Product Description
Drying insulating varnish with excellent conductivity and insulation excellent heat dissipation performance
1. product description
8562E is made of modified alkyd resin and amino resin. The paint film has a combination of high solids. It is mainly designed to protect and provide high insulation performance for electrical products. This product can provide excellent electrical conductivity and insulation after fully cured. And has excellent heat dissipation performance, and can reduce product oscillation, noise, temperature rise, magnetic leakage and other phenomena. Low-temperature cross-linking and curing, excellent electrical conductivity and insulation, high flexibility, strong water resistance, dust resistance, antistatic, moisture, rust and corrosion resistance.
2. Precautions
In order to ensure the stability of the paint, please do not stir the paint forcefully to avoid air bubbles in the product. After soaking and standing for about 10 minutes, it can be placed in an oven above 80℃ to accelerate the curing of the paint film. The higher the temperature, the shorter the baking time.
3. technical parameter
| Parameter | Typical value | Parameter | Typical value |
| Main ingredients | modified alkyd resin and amino resin | Appearance | full gloss/varnish |
| Color | ≤3 Gardner (Gardner standard) | Proportion | about 0.92 |
| Viscosity | 30±2Sec(25℃ Ford Cup#4) | Insulation degree | >3KV@30UM (dry film meter) |
| Coverage area | 1.5 square meters/liter | Drying time | The baking time is generally not less than 2 hours |
| The baking temperature | generally not less than 80℃ | Best baking temperature | 120℃-140℃ |
| Solid content | about 43% | Shelf life | 6 months |
4.Dry paint picture
